ShareWiz Ultra Secure Server Setup
DNS Security
DNS Security
Introduction
DNS (Domain Name System) is one of the core component of web that provides us human friendly domain names, mapped to computer friendly numeric address (called I.P (Internet Protocol) Address).
Each time – when you visit a website – your computer/browser performs a DNS query (searching for IP address for the requested domain name (website you visit)).
By default the server caches DNS results in order to provide fast lookup in future, which is really good, because it’s efficient and saves a lot of resources, but occasiobnally this creates a problem specially when a domain gets a new IP address(s) (or in other words, the server is changed).
Spoofing DNS cache
DNS is a distributed database with a hierarchical structure used to translate the human friendly host names into the IP address, in TCP/IP Networks.
So when a computer wants to communicate with www.sharewiz.net then it first sends a query to the local DNS server and the dns server checks its databases to find the corresponding ip address.
If the local server fails then it tries to communicate with the other remote dns servers, and finally it returns the corresponding IP address to the users computer (If there is no problem on the sharewiz.net servers).
After this event the users computer and local dns server (if failed to resolve) updates its database so that in future it can use that ip address-host name maps without any further queries with the other dns servers.
There are many available methods for spoofing the dns cache but the simple concept is to alter the corresponding map between the host name and IP address in the dns cache of the victim computer or dns server.
Two simple methods to poison the DNS cache
- Hacker sends a dns query to the local dns and before the local dns server gets the true result fr0m the remote server, the local dns server is flooded by the fake reply from the hacker, thus the local dns cache gets spoofed.
- The hacker poisons the host names by their fake website IP address, so when the user sends the request to the infected dns server, then it maps to the fake website.
The caching has a component called time to live (TTL) and the TTL determines how long a server will cache a piece of information.
Install Bind
Issue the following command:
sudo aptitude install bind9
Configure Bind
Issue the following command:
sudo vi /etc/bind/named.conf.options
and add 2 DNS servers to use as master servers:
forwarders {
# Replace the address below with a known DNS server
8.8.4.4;
8.8.8.8;
};
The two added DNS servers used as master servers are actually Google's DNS servers.
They are added so that the local server has a source for IP addresses that are not provided for locally.
Configure Resolvconf
Issue the following command:
sudo vi /etc/resolvconf/resolv.conf.d/base
and add 2 DNS servers to use as master servers:
domain server1.sharewiz.net
search server1.sharewiz.net
nameserver 8.8.4.4
nameserver 8.8.8.8
nameserver 127.0.0.1
options rotate
Ubuntu now ships with a dynamic resolv.conf manager called resolvconf, which handles editing /etc/resolv.conf for us. Thus, instead of editing /etc/resolv.conf, we can edit /etc/resolvconf/resolv.conf.d/base.
The two added DNS servers used as master servers are actually Google's DNS servers.
They are added so that the local server has a source for IP addresses that are not provided for locally.
Restart Resolvconf
To enable the new settings to be recognized, restart Bind.
Issue the following command:
sudo service resolvconf restart
Restart Bind
To enable the new settings to be recognized, restart Bind.
Issue the following command:
sudo service bind9 restart
Test Bind
Issue the following command:
sudo dig www.google.com
which should show something like:
; <<>> DiG 9.8.1-P1 <<>> www.google.com
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 45194
;; flags: qr rd ra; QUERY: 1, ANSWER: 7, AUTHORITY: 13, ADDITIONAL: 0
;; QUESTION SECTION:
;www.google.com. IN A
;; ANSWER SECTION:
www.google.com. 84705 IN CNAME www.l.google.com.
www.l.google.com. 300 IN A 74.125.132.103
www.l.google.com. 300 IN A 74.125.132.104
www.l.google.com. 300 IN A 74.125.132.105
www.l.google.com. 300 IN A 74.125.132.106
www.l.google.com. 300 IN A 74.125.132.147
www.l.google.com. 300 IN A 74.125.132.99
;; AUTHORITY SECTION:
. 59063 IN NS c.root-servers.net.
. 59063 IN NS i.root-servers.net.
. 59063 IN NS k.root-servers.net.
. 59063 IN NS h.root-servers.net.
. 59063 IN NS a.root-servers.net.
. 59063 IN NS l.root-servers.net.
. 59063 IN NS j.root-servers.net.
. 59063 IN NS g.root-servers.net.
. 59063 IN NS e.root-servers.net.
. 59063 IN NS d.root-servers.net.
. 59063 IN NS b.root-servers.net.
. 59063 IN NS f.root-servers.net.
. 59063 IN NS m.root-servers.net.
;; Query time: 189 msec
;; SERVER: 127.0.0.1#53(127.0.0.1)
;; WHEN: Mon Jul 9 19:06:52 2012
;; MSG SIZE rcvd: 359
The providing DNS server should be 127.0.0.1. This can be seen in the line near the bottom of the output: SERVER: 127.0.0.1#53(127.0.0.1)
Configure Local Bind
Issue the following command:
sudo vi /etc/bind/named.local.options
and populate as follows:
# This is the zone definition. replace server1.sharewiz.net with your domain name
zone "server1.sharewiz.net" {
type master;
file "/etc/bind/zones/server1.sharewiz.net.db";
};
# This is the zone definition for reverse DNS. replace 1.168.192 with your network address in reverse notation . e.g my network address is 192.168.1
zone "1.168.192.in-addr.arpa" {
type master;
file "/etc/bind/zones/rev.1.168.192.in-addr.arpa";
};
Restart Bind
Issue the following command:
sudo mkdir -p /etc/bind/zones
Create Zone File
Issue the following command:
sudo vi /etc/bind/zones/server1.sharewiz.net.db
and populate as follows:
// replace example.com with your domain name. do not forget the . after the domain name!
// Also, replace ns1 with the name of your DNS server
server1.sharewiz.net. IN SOA admin.server1.sharewiz.net.
// Do not modify the following lines!
2006081401
28800
3600
604800
38400
)
// Replace the following line as necessary:
// ns1 = DNS Server name
// mta = mail server name
// example.com = domain name
server1.sharewiz.net. IN NS admin.server1.sharewiz.net.
server1.sharewiz.net. IN MX 10 mta.server1.sharewiz.net.
// Replace the IP address with the right IP addresses.
www IN A 192.168.1.1
mta IN A 192.168.1.1
admin.server1 IN A 192.168.1.1
Create Zone File
Issue the following command:
sudo vi /etc/bind/zones/rev.1.168.192.in-addr.arpa
and populate as follows:
// replace example.com with your domain name, ns1 with your DNS server name.
// The number before IN PTR example.com is the machine address of the DNS server
@ IN SOA server1.sharewiz.net admin.sharewiz.net. (
2006081401;
28800;
604800;
604800;
86400
)
IN NS server1.sharewiz.net.
1 IN PTR server1.sharewiz.net
Restart Bind
To enable the new settings to be recognized, restart Bind.
Issue the following command:
sudo service bind9 restart
Test Bind
Issue the following command:
sudo dig www.google.com
which should show something like:
; <<>> DiG 9.8.1-P1 <<>> www.google.com
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 45194
;; flags: qr rd ra; QUERY: 1, ANSWER: 7, AUTHORITY: 13, ADDITIONAL: 0
;; QUESTION SECTION:
;www.google.com. IN A
;; ANSWER SECTION:
www.google.com. 84705 IN CNAME www.l.google.com.
www.l.google.com. 300 IN A 74.125.132.103
www.l.google.com. 300 IN A 74.125.132.104
www.l.google.com. 300 IN A 74.125.132.105
www.l.google.com. 300 IN A 74.125.132.106
www.l.google.com. 300 IN A 74.125.132.147
www.l.google.com. 300 IN A 74.125.132.99
;; AUTHORITY SECTION:
. 59063 IN NS c.root-servers.net.
. 59063 IN NS i.root-servers.net.
. 59063 IN NS k.root-servers.net.
. 59063 IN NS h.root-servers.net.
. 59063 IN NS a.root-servers.net.
. 59063 IN NS l.root-servers.net.
. 59063 IN NS j.root-servers.net.
. 59063 IN NS g.root-servers.net.
. 59063 IN NS e.root-servers.net.
. 59063 IN NS d.root-servers.net.
. 59063 IN NS b.root-servers.net.
. 59063 IN NS f.root-servers.net.
. 59063 IN NS m.root-servers.net.
;; Query time: 189 msec
;; SERVER: 127.0.0.1#53(127.0.0.1)
;; WHEN: Mon Jul 9 19:06:52 2012
;; MSG SIZE rcvd: 359
The providing DNS server should be 127.0.0.1. This can be seen in the line near the bottom of the output: SERVER: 127.0.0.1#53(127.0.0.1)
Test Bind another way
Issue the following command:
sudo nslookup www.google.com
which should show something like:
Server: 8.8.8.8
Address: 8.8.8.8#53
Non-authoritative answer:
www.google.com canonical name = www.l.google.com.
Name: www.l.google.com
Address: 74.125.132.147
Name: www.l.google.com
Address: 74.125.132.104
Name: www.l.google.com
Address: 74.125.132.106
Name: www.l.google.com
Address: 74.125.132.99
Name: www.l.google.com
Address: 74.125.132.103
Name: www.l.google.com
Address: 74.125.132.105
and now try the same using the local bind9 DNS server:
sudo nslookup www.google.com 127.0.0.1
which should show something like:
Server: 127.0.0.1
Address: 127.0.0.1#53
Non-authoritative answer:
www.google.com canonical name = www.l.google.com.
Name: www.l.google.com
Address: 74.125.132.147
Name: www.l.google.com
Address: 74.125.132.104
Name: www.l.google.com
Address: 74.125.132.106
Name: www.l.google.com
Address: 74.125.132.99
Name: www.l.google.com
Address: 74.125.132.103
Name: www.l.google.com
Address: 74.125.132.105
If the The providing DNS server at 127.0.0.1 does not return successfully, then bind is not working.
An error such as the following indicates that bind is not running, so simply start it and retry:
;; connection timed out; no servers could be reached
Install Bind
Issue the following command:
sudo aptitude install nscd
By default, our computer cache DNS results in order to provide fast lookup in future - and that’s really good (because it’s efficient and saves a lot of resources), but some times it creates a problem specially when a domain gets new IP address(s) (or in other words, the server is changed).
In such case the cached result may prevent you from viewing the latest website/app for your domain. So that’s where – flushing the DNS cache results, is mandatory.
There are various ways to clear dns cache in Ubuntu but using nscd (name service cache daemon) is very simple and straightforward (and it works with almost all – commonly used GNU/Linux distributions such as Fedora, Mint, OpenSuse etc).
Clear DNS CACHE
Issue the following command:
sudo /etc/init.d/nscd restart
For further help, issue the command sudo nscd -help.
